NOTE: Installing the panels in any other position other than shown will result in flame im-
pingement causing sooting of the logs, brick liner and ceramic glass viewing area.
Right Brick Panel Placement as Shown
2nd Panel
3rd Panel
Use existing screws to secure brick clip
& hold panel. Repeat for left side
The top baffle rests on the side panels
