Archgard Optima 70-2 - Replacement Parts List

Optima 70 - 2 48
REPLACEMENT PARTS LIST ARCHGARD OPTIMA 70
Item # Item Description Qty Unit
200-0162 Owners Manual 1 EA
300-0031 Magnet Pull (holds bottom louver) 2 EA
300-0034 Catch, Door Latch. (Buckle for door) 2 EA
308-0005 Piezo Igniter Only 1 EA
700-0140 Vent Restrictor #1 1 EA
700-0141 Vent Restrictor #2 1 EA
308-0046 Knob Extension - ON/OFF 1-/12” (62 mm) 1 EA
308-0047 Knob Extension - HI/LOW 1-1/2” (62 mm) 1 EA
Fan Components
305-0013 Fan - Speed Control (Rheostat) 1 EA
305-0017 Fan - Junction Box Cover Plate 1 EA
305-0018 Fan - Junction Box 1 EA
305-0021 Fan - Thermodisc (fan sensor) 110
0
F. (43
0
Celsius) 1 EA
305-0024 Fan - Fan with motor and blades. 120VAC, 115V, 24watt (QLN65-
0018)
1 EA
702-0047 Fan - Thermodisc mounting bracket 1 EA
702-0050 Fan - Fan Heat Shield 1 EA
Flat Glass Door
813-0076 Complete Replacement Door. Includes, glass, gasket and door
frame
1 EA
Ceramic Brick
311-0017 Ceramic Brick Liner - Right Side 1 EA
311-0018 Ceramic Brick Liner - Left Side 1 EA
311-0060 Ceramic Brick Liner - Rear 1 EA
702-0044 Brick Panel Clips 2 EA
Replacement parts for BBAY-70 Bay Door
300-0031 Magnet Pull 2 EA
307-0030 Glass, 6mm Tempered (Middle Piece) 1 EA
307-0031 Glass, 6mm Temp (Side Piece) 2 EA
308-0048 Knob Ext. ON/OFF 2-1/2” (63 mm) 1 EA
308-0049 Knob Ext. HI/LOW 2-1/2” (63 mm) 1 EA
314-0006 Gasket Flat 72 IN
