44
NOTE: High engine RPM, low vehi-
cle speed, or heavy load can raise
engine temperature. Decreasing
engine RPM, reducing load, and
selecting an appropriate transmis-
sion gear can lower the temperature.
NOTE: Debris in front of the
engine (or packed between the
cooling fins of the radiator) can
reduce cooling capacity. Using a
garden hose, wash the radiator and
the engine to remove any debris
restricting air flow.
3. Mode Button - Shifts the gauge
through three set-up modes: speed-
ometer/tachometer, distance, and
time.
NOTE: The Mode Button must be
pressed and released to shift
modes. Approximately two seconds
after the Mode Button is released,
the digital gauge will return to full
display.
4. Set/Reset Button - In conjunction
with the Mode Button, sets and resets
various displays on the digital gauge.
Also used to shift from speedometer
function to tachometer function on
the speedometer/tachometer gauge.
5. Fuel Level Indicator - Indicates
approximate amount of gasoline in
the gas tank.
NOTE: When the bottom seg-
ment flashes, approximately 3.5 L
(0.92 U.S. gal.) of gasoline remains
in the tank.
6. Low Oil Pressure - Will be displayed
during self-test at start-up. It will not
be displayed during normal operation
as oil pressure is not monitored on
these models.
7. Odometer/Trip Meter - Odometer reg-
isters the total distance the vehicle has
traveled. The trip meter is resetable
and can be used to measure trip or trip
legs. The odometer cannot be reset.
NOTE: To shift between the odom-
eter (ODO) or trip meter (TRIP),
press the Mode Button (3) to select
the distance mode; then press the
Set/Reset Button (4) to select the
desired display. Hold the Set/Reset
Button down to reset the trip meter.
8. Gear Position Indicator - Indicates
which gear position is selected.
• R (reverse)/N (neutral)/L (low range)/H
(high range)
NOTE: An E will be displayed if
there is an error caused by a no-
shift position signal.
9. High Beam Indicator - The High
Beam icon will appear only when the
headlights are on high beam.
10.
4WD Lock Indicator - Displays
LOCK when the front differential
lock has been engaged. Not utilized
on this model.
11. Speedometer - Indicates the approxi-
mate vehicle speed in miles per hour
(MPH) or kilometers per hour (km/h).
NOTE: To change mph/km/h dis-
play, press and release Mode But-
ton (3) until the icon (MPH/km/h)
appears; then press the Set Button
(4) to change the display.
Speedometer/LCD
Gauge (Digital)
1. Clock/Engine Hour Meter - The
clock function indicates time in the
12-hour mode; the hour meter indi-
cates the total time the ATV has run
and cannot be reset to zero. To set
the clock, use the following proce-
dure.
CAUTION
Arctic Cat does not recommend
using a pressure washer to clean the
radiator core. The pressure may bend
or flatten the fins causing restricted
air flow, and electrical components
on the radiator could be damaged.
Use only a garden hose with spray
nozzle at normal tap pressure.
