Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
67
ITIM
PARTS NO.
DESCRIPTION
1
6031
DRAWBAR FOR
2
6032
DRAWBAR WASHER
3
6041
UPPER BEARING LOCKNUT
4
6042
BEARING SLEEVE LOCKNUT
5
6043
BALL BEARING
6
6044
UPPER BEARING SPACER (SMALL)
7
6045
UPPER BEARING SPACER (LARGE)
8
6043
BALL BEARING
9
6049
COMPRESSION SPRING (4 REQ.)
10
6249
SOCKET SET SCREW (2 REQ.)
11
6047
SPINDLE PULLEY BEARING SLEEVE
12
6019
JAM NUT
13
6022
EXTERNAL LOCK WASHER
14
6018
BRAKE RING SCREW (3 REQ.)
15
6024
SPRING (2 REQ.)
16
6025
MACHINE SCREW (4 REQ.)
17
6020
BRAKE LOCK STUD
18
6014
BRAKE ASSEMBLY
19
6048
SPINDLE PULLEY
20
6040
SPINDLE PULLEY HUB
22
6034
V BELT
23
6035
TIMING BELT
24
6072
TIMING BELT PULLEY FLANGE
25
6071
TIMING BELT PULLEY
26
6072
TIMING BELT PULLEY FLANGE
27
6073
FLAT HEAD SCREW
28
6070
HEX. JAM NUT
29
6038
BLACK PLASTIC BALL HANDLE (2 REQ.)
30
6037
SPINDLE CLUTCH LEVER
31
6036
CAM RING
32
6039
CAM RING PIN (2 REQ.)
33
6023
SOCKET SET SCREW
34
6016
BRAKE LOCK HANDLE
35
6021
BRAKE LOCK PIN
39
6008
HEX JAM NUT (2 REQ.)
41
6002
MOTOR MUNTING STUDS (2 REQ.)
42
6013
BELT HOUSING
