Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
68
ITIM
PARTS NO.
DESCRIPTION
43
6003
MOTOR LOCKNUT (2 REQ.)
45
6006
MOTOR LOCKNUT HANDLE (2 REQ.)
46
6007
BLACK PLASTIC BALL (2 REQ.)
49
6009
MOTOR PULLEY
50
6078
GEAR HOUSING COVER
51
6080
ROUND HD SCREW (5 REQ.)
55
6079
OIL CUP
56
6075-1
BULL GEAR KEY
57
6075
SPLINDLE GEAR HUB
58
6074
SPINDLE BULL GEAR ASSEMBLY
59
6056
BEARING
60
6068
COUNTERSHAFT
61
6069
KEY
62
6067
COUNTERSHAFT GEAR
63
6056
BEARING
64
6066
DOWEL PIN
65
6065
BACK GEAR SHIFTER FORK
66
6050
GEAR HOUSING
67
6051
DOWEL PIN (2 REQ.)
68
6052
ROLL PINS (2 REQ.)
69
6057
SOCKET CAP SCREW (6 REQ.)
71
6053
BALL BEARING
72
6054
SNAP RING
73
6077
LOCKWASHER
74
6076
BEARING LOCKUNT
75
6083
HEX NUT HARDENED (3 REQ.)
76
6081
VERTICAL TEE BOLT (3 REQ.)
77
6082
VERTICAL BOLT WASHER (3 REQ.)
78
6060
BACK GEAR SHIFT CRANK
79
6167
ROLL PIN
80
6058
BACK GEAR SHIFT BUSHING
81
6168
SHIFT CRANK
82
6171
BLACK PLASTIC BALL 1” DIA
83
6169
GEARSHIFT PLUNGER
84
6170
COMPRESSION SPRING
85
6026
BELT GUARD ASSEMBLY
