Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
70
ITIM
PARTS NO.
DESCRIPTION
1
H8001
SOCKET CAP SCREW (3 REQ.)
4
H8004
BALL BEARING
5
H8005
SNAP RING NO.
7
H8007
HEX JAM NUT
8
H8008
MOTOR (COMPLETE NUT)
9
H8009
HEX HD SCREW (2 REQ.)
10
H8010
BELT HOUSING
13
H8013
SPEED CHANGE PLATE
14
H8014
DRAWBAR
15
H8015
COTTER PIN
16
H8016
SPEED CHANGE PLATE PIVIOT STUD
17
H8017
SOCKET HD CAP SCREW (2 REQ.)
18
H8018
WASHER
19
H8019
PIVOT SLEVE (2 REQ.)
20
H8020
DRAW BAR WASHER
22
H8022
SPINDLE PULLEY BEARING SLIDING HOUSING
23
H8023
BALL BEARING
24
H8024
PLASTIC INSERT (2 REQ.)
25
H8025
ADJUSTABLE-DRIVEN VARIDISC
26
H8026
SNAP RING NO.
27
H8027
BELT
28
H8028
STATIONARY DRIVEN VARIDISC
29
H8029
BRAKE BEARING CAP
29A
H8029-1
SOCKET HD CAP SCREW (2 REQ.)
31
H8031
BRAKE SPRING (2 REQ.)
32
H8032
BRAKE SHOE ASSEMBLY (2 REQ.)
33
H8033
SPINDLE PULLEY SPACER
34
H8034
SPINDLE PULLEY HUB
35
H8035
HEX HD. SCREW
36
H8036
BRAKE SHOE PIVOT SLEEVE
37
H8037
ROLL DOWEL PIN
38
H8038
DRIVE KEY
39
H8039
KEY FOR ADJ VARIDISC MOTOR SHAFT
40
H8040
STATIONARY MOTOR VARIDISC
41
H8041
SOCKET SET SCREW
42
H8042
PLASTIC INSERT (2 REQ.)
43
H8043
ADJUSTABLE MOTOR VARIDISC ASSEMBLY
