Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
71
ITIM
PARTS NO.
DESCRIPTION
44
H8044
SPRING FOR VARIDISC MOTOR SHAFT
45
H8045
ADJUSTABLE VARIDISC SPRING COLLAR
46
H8046
SOCKET HD CAP SCREW (2 REQ.)
47
H8047
RET. RING
48
H8048
SOCKET CAP SCREW
49
H8049
PLASTIC KEY
51
H8051
KEY
52
H8052
TAPER PIN
53
H8053
BELT HOUSING BASE
54
H8054
MOTOR PULLEY COVER
55
H8055
SOCKET CAP SCREW
58
H8058
HI-LOW RANGE NAMEPLATE
59
H8059
DRIVE SCREW (4 REQ.)
60
H8060
TAPER PIN (2 REQ.)
61
H8061
QUILL FEED NEMEPLATE
62
H8062
REIVETS (4 REQ.)
63
H8063
GEAR HOUSING
64
H8064
SOCKET CAP SCREW (6 REQ.)
66
H8066
SNAP RING
67
H8067
BRAKE FINGER PIVOT STUD
68
H8068
BRAKE OPERATING FINGER
69
H8069
BRAKELITE BALL HANDLE
70
H8070
BRAKE LOCK HANDLE
71
H8071
BRAKE LOCK PIN
72
H8072
SOCKET SET SCREW
73
H8073
SLEEVE FOR BRAKE LOCK SHAFT
74
H8074
BRAKE LOCK SHAFT
75
H8075
BUSHING
77
H8077
SOCKET SET SCREW
