Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
73
ITIM
PARTS NO.
DESCRIPTION
1
H7001
HEX CAP NUT
2
H7002
VARI-SPEED DIAL
3
H7003
BRONZE BEARING
4
H7004
FULL DOG SOCKET SET SCREW
5
H7005
SPEED CHANGER HOSING
9
H7008
ROLL PIN
9-1
H7008-1
ROLL PIN
9A
H7008-2
ROLL PIN
9B
H7008-3
SPEED CHANGE STUD
9C
H7008-4
COTTER PIN
10
H7010
SPEED CHANGER CHAIN
13
H7013
TOP BEARING CAP
15
H7015
ROLL PIN
16
H7016
SPRING
17
H7017
BEARING
18
H7018
SPEED CHANGE SHAFT
19
H7019
HANDLE
20
H7020
CAUTION PLATE
21
H7021
SPEED CHANGE HANDWHEEL
22
H7022
FLAT HD. CAP SCREW (2 REQ.)
23
H7023
PLASTIC FACE PLATE
24
H7024
SET SCREW
25
H7025
SOCKET HD CAP SCREW (4 REQ.)
30
H7030
WORM GEAR
31
BEARING
33
H7033
SPEED CHANGER SPUR GEAR
35
H7035
SPEED CHANGE CHAIN DRUM
36
H7036
BELT
38
H7038
TIMING PULLEY CLUTCH SLEEVE
39
H7039
SPINED GEAR HUB
40
H7040
SPINDLE BULL GEAR ASSEMBLY
41
H7041
BALL BEARING (2 REQ.)
42
H7042
SNAP RING (2 REQ.)
43
H7043
BULL GEAR BEARING SPACER
45
H7045
VERT. TEE BOLTS (3 REQ.)
46
H7046
STEEL WASHER (3 REQ.)
48
H7048
BALL BEARING GEAR SLEEVE WASHER
