Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
74
ITIM
PARTS NO.
DESCRIPTION
49
H7049
FIXED CLUTCH BRACKET
50
H7050
OIL CUP
51
H7051
GUIDE FOR CLUTCH BRACKET
52
H7052
FLAT HD SOCKET CAP SCREW (2 REQ.)
53
H7053
DOWEL PIN
54
H7054
OIL CUP
55
H7055
COMPRESSION SPRING (3 REQ.)
56
H7056
BEARING LOCKNUT
57
H7057
BEARING SLEEVE
58
H7058
WAVE SPRING WASHER
59
H7059
BULL GEAR SHIFT PINION
60
H7060
HI-LOW DETENT PLATE
61
H7061
HEX NUT (3 REQ.)
62
H7062
LOCK WASHER (3 REQ.)
63
H7063
STUDS (3 REQ)
64
H7064
SOCKET SET SCREW
65
H7065
ADJUSTABLE PLATE
66
H7066
HI-LOW DETENT PLUNGER
67
H7067
SPRING
68
H7068
SOCKET SET SCREW
69
H7069
BAKELITE BALL HANDLE
70
H7070
HI-LOW SHIFT CRANK
71
H7071
HI-LOW PINION BLOCK
72
H7072
ROLL PIN (1 REQ.)
72A
H7072A
SOCKET HD CAP SCREW (2 REQ.)
73
H7073
SOCKET CAP SCREW (4 REQ.)
77
H7077
SOCKET SET SCREW
78
H7078
KEY (2 REQ.)
79
H7079
BALL BEARING (2 REQ.)
80
H7080
BULL GEAR PINION COUNTER SHAFT
81
H7081
KEY
82
H7082
WAVE SPRING WASHER
84
H7084
BULL GEAR PINION BEARING CAP
85
H7085
SOCKET HD CAP SCREW (2 REQ.)
86
H7086
TIMING BELT PULLEY
87
H7087
JAM NUT
88
H7088
VENTILATOR (2 REQ.)
