Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
80
ITIM
PARTS NO.
DESCRIPTION
127
6084
SPINDLE
128
6086
QUILL SKIRT
129
6090
LOCNUT
130
6091
LOCKWASHER
131
6092
BEARING
132
6094
SLEEVE
133
6098
NOSE-PIECE
134
6097
SPINDLE DIRT SHIELD
135
6093
BEARING
138
6093
BEARING
136
6095
BEARING SPACER-LARGE
137
6096
BEARING SPACER-SAMLL
140
6253
SPECIAL SOCKET SET SCREW
141
6254
COLLET ALIGNMENT SCREW
142
6085
QUILL
144
6113
SOCKET SET SCREW
145
6111
FEED TRIP LEVER
146
6112
TRIP LEVER PIN
148
6116-1
QUILL LCOK SLEEVE
149
6119
LOCK HANDLE
152
6117
QUICK LOCK BOLT
151
6088
FELT WASHER
153
6116
QUILL LOCK SLEEVE TAPPED
155
5036
T-BOLT ASSY
156
6120
LOWER CLAMPING BOLT SPACER (2 REQ.)
157
5038
LOCKNUT
158
6244
CHEM BLACKED RD. HD. SCREW (2 REQ.)
159
6243
MICROMETER SCALE
160
6115
SNAP RING
161
6108
QUILL MICRO-STOP NUT
162
6107
MICROMETER NUT
164
6104
QUILL STOP MICRO-SCREW
163
6105
QUILL STOP KNOB
165
6106
SCREW
166
6172
QUILL PINION SHAFT
168
6185
SPRING PIN
169
6180-1
RD. HEAD SCREW (2 REQ.)
