CH10 零件圖 Spare Parts Drawing Original
81
ITIM
PARTS NO.
DESCRIPTION
170
6179
ROLL PIN
171
6184
KEY
172
6183
PINION SHAFT HUB SCREW
173
6176
STEEL BALL
174
6175
COMPRESSION SPRING
175
6178
RACKFEED HANDLE HUB
176
6182
PINION SHAFT HUB SLEEVE
177
6180
SPRING COVER
178
6181
CLOCK SPRING (CLOCK SPRING ASSY)
181
6246-1
SOCKET SET SCREW
182
6246
LOCKSCREW
183
6110
REVERSE TRIP BALL LEVER
184
6109
FEED REVERSE TRIP PLUNGER
185
6114
REVERSE TRIP BALL LEVER SCREW
186
5039
WORM GEAR
187
5041
KEY
188
5042
SOCKET SET SCREW
189
5040
ADJ WORM SHAFT
190
6174
PINION SHAFT HUB HANDLE
191
6173
BLACK PLASTIC BALL HANDLES
192
6101
QUILL HOUSING
