2 & 4 Element Electric Boiler
Item Part Number Description
1 V1 Relief Valve - 30 PSI
2 E1 Elbow 3/4" x 90°
3 N1 Nipple 3/4" x 2"
4 B28 Circuit Breaker 15 A - 1 Pole - G.E. THQP 115
5 B27 Circuit Breaker 40 A - 2 Pole - G.E. THQP 240
6 I25 Load Center Assemly - G. E. TLM812U2
7 109008918 Cabinet
8
L9 Ground Lug
9 B194 Nuetral Terminal Block
10 P23 Chassis, Back/Bottom
11
C57 Pressure Vessel - Cast Iron, 2 Element
C32 Pressure Vessel - Cast Iron, 4 Element
12
240010295 Control Board - 2 Element, kit, includes wires
240010296 Control Board - 4 Element, kit, includes wires
13
E13 Heating Element - 3KW/240 Volt
E14 Heating Element - 4KW/240 Volt
E15 Heating Element - 5KW/240 Volt
E16 Heating Element - 6KW/240 Volt
13a S66 Bolt, 5/16 - 18 x 3/4
13b W29 Washer, Flat 5/16"
14 G12 Gasket, Heating Element
15 S47 Safety Limit Control (High Limit, Fixed Temperature)
16 119000002 Transformer 115/24V, 40VA
17 240010289 Water Temperature Sensor Kit
18 240004756 Brass Well
PARTS LIST - 2 & 4 ELEMENT BOILER
