INSTALLATION MANUAL AND OPERATING
INSTRUCTIONS
Table 1 -AT Boiler Electrical Specications
Operating at 240 Vac
“AT” Series - 2 Element Boiler *Recommended Wire
Model
Boiler Size
Nominal
kW
Voltage
(AC)
Output
Power
(Watts)
Output
Power
BTU/Hr.
Amperage
Element
Size
(Watts)
at
240Vac
Number
Elements
Accessory
Load (A)
Total
Amps
MCA MOP
60°C
(140ºF)
AWG
75°C
(167ºF)
AWG
90°C
(194ºF)
AWG
AT0623 6 240 6,000 20,500 25.0 3,000 2 6 31.0 38.8 40.0 8 8 10
AT0824 8 240 8,000 27,300 33.3 4,000 2 6 39.3 49.2 50.0 6 8 8
AT1025 10 240 10,000 34,100 41.7 5,000 2 6 47.7 59.6 60.0 4 6 6
AT1226 12 240 12,000 41,000 50.0 6,000 2 6 56.0 70.0 70.0 4 4 6
“AT” Series - 4 Element Boiler
AT1243 12 240 12,000 41,000 50.0 3,000 4 6 56.0 70.0 70.0 4 4 6
AT1644 16 240 16,000 54,600 66.7 4,000 4 6 72.7 90.8 100.0 2 3 4
AT2045 20 240 20,000 68,200 83.3 5,000 4 6 89.3 111.7 125.0 1/0 2 2
AT2446 24 240 24,000 82,000 100.0 6,000 4 6 106.0 132.5 150.0 2/0 1/0 1
Operating at 208 Vac
“AT” Series - 2 Element Boiler
*Recommended Wire
AT0623 6 208 4,507 15,400 21.7 3,000 2 6 27.7 34.6 35.0 8 10 10
AT0824 8 208 6,009 20,500 28.9 4,000 2 6 34.9 43.6 45.0 6 8 8
AT1025 10 208 7,511 25,600 36.1 5,000 2 6 42.1 52.6 60.0 6 6 8
AT1226 12 208 9,013 30,800 43.3 6,000 2 6 49.3 61.7 70.0 4 6 6
“AT” Series - 4 Element Boiler
AT1243 12 208 9,013 30,800 43.3 3,000 4 6 49.3 61.7 70.0 4 6 6
AT1644 16 208 12,018 41,000 57.8 4,000 4 6 63.8 79.7 80.0 3 4 4
AT2045 20 208 15,200 51,200 72.2 5,000 4 6 78.2 97.8 100.0 1 3 3
AT2446 24 208 18,027 61,600 86.7 6,000 4 6 92.7 115.8 125.0 1/0 1 2
MCA = Minimum Circuit Ampacity
MOP = Maximum Over-current protection
*Recommended Field Wire Size per NEC Table 310.16
Not more than three (3) current carrying conductors in raceway
Based on ambient temperature of 30ºC (86ºF). Other ambient temperatures see NEC or CEC for correction factors.
Use Copper conductors only.
Recommended use only Class B or C type wire (see Table B).
Check with latest version of NEC and local codes.
UL-834, Section 14.2
Assuming 60ºC (140ºF) wire will be used for connections to boiler rated at 80 amperes or less, and 75ºC (167ºF) wire will
be used with boiler rated at more than 80 amperes.
VOLTAGE RATING TABLES
