PUMP CONFIGURATIONS
14.203.B_A707 en.SM.V4.3X ARGUS Medical AG 28.03.06 / PJ 5 / 48
2. Press the
“START/
STOP” key.
4. To quit the interro-
gation mode press
the “ON/OFF” key
at least 2 seconds.
3. Enter the requested address (see
chapter 2.6), e.g. 5. The pro-
grammed value of the address 5
appears in the right hand display.
2.2. Interrogation mode (without ARGUS service)
With the interrogation mode you can read the present keypad configuration of the
pump without the possibility to modify any configurations. For a complete overview,
please take the “ARGUS service” PC-tool!
Flashing decimal points indicate which display is ready to accept an input by the
keys 100, 10 & 1.
In the interrogation mode the left hand display shows the address and the right
hand display shows the according value configured at this address. Please refer
to chapter 2.6. where the meanings of the addresses are explained.
To modify any configuration data you have to go into the configuration mode.
1. To enter into the interrogation mode, switch the pump on while
keeping the keys “MODE” and “START/STOP” pressed.
