MAINTENANCE
14.164.A_A707en.SM.V1.01.doc ARGUS Medical AG 10.02.04 AS 26 / 38
5.7. Fault codes
A technical failure will be signalled by the pump with a continuous alarm display and a
continuous sound. During this state, the fault code which causes the pump to fail can be
displayed by pressing the key “MODE”.
IF the pump was switched OFF after a detected failure, the fault code will be stored in the
configuration of the pump, please refer to chapter 2.6 (Addresses 380-389).
The possible fault codes registered in the configuration are listed in the table below:
Fault
Code
Failure
F_21 ROM test
F_22 ROM check (Runtime)
F_23 RAM test/check
F_24 XRAM test/check
F_25 CPU test
F_26 Invalid function menu
F_27 EEPROM data invalid
F_28 RTC data invalid, no RTC etc
F_29 Stepper motor power test (delayed 5s)
F_32 5Volt supply out of range
F_33 24Volt supply out of range (delayed 5s)
F_37 Downstream pressure sensor test failed (always > 4.7V, delayed 5s
F_38 Upstream pressure sensor test failed (always > 4.7V, delayed 5s)
F_39 Downstream pressure sensor test failed (dynamical test failed)
F_40 Upstream pressure sensor test failed (dynamical test failed)
F_44 Address invalid for config-eeprom
F_45 Address invalid for history-eeprom
F_46 Frequency from uC or RTC out of range
F_47 Display-print not present
F_48 Key(s) too long active
F_49 Sensor-print not present
F_50 AIL (Air in line) detector test failed
F_51 Movement test failed (Home-Pulse < (Hall / Home))
F_52 Movement test failed (Home-Pulse > (Hall / Home))
F_53 More than one rotation at 'STOP' without 'KVO'
F_54 Infused sum <> Calculated sum (Rotations)
F_55 Frequency calculation
F_57 Rotation (SW overflow)
F_58 Volsum control
We recommend replacing the main board in case a fault code is not included in this list
above.
