PUMP CONFIGURATIONS
14.164.A_A707en.SM.V1.01.doc ARGUS Medical AG 10.02.04 AS 9 / 38
Add. Def. P Function Range
50 0 W Start with >= 1bar downstream pressure allowed 0=No; 1=Yes
55 0 W Set default serial interface to RJ-45 connector 0=No; 1=Yes
60 0 W KVO only after infusion completed 0=No; 1=Yes
101 1 Set 1 enabled (always enabled) 0=No; 1=Yes
201 1091 W
202 1071 W
203 1061 W
204 1051 W
205 1031 W
206 1023 W
207 1014 W
208 1006 W
209 999 W
210 988 W
211 974 W
212 967 W
213 947 W
214 939 W
215 917 W
216 900 W
217 1000 W
306 0 Infused sum in ml (xxxxyyyy) [xxxx.... ml]
307 0 Infused sum in ml (xxxxyyyy) [....yyyy ml]
308 0 Operating time in min (xxxxyyyy) [xxxx.... min]
309 0 Operating time in min (xxxxyyyy) [....yyyy min]
310 9999 W
Max. rate in (1/10)ml/h
(1...9999)
311 999 W Prime rate in ml/h (1...999)
312 1200 W Max. bolus rate in ml/h (1...1200)
313 10 W Max. bolus total in ml (1...999)
314 10 W Upstream occlusion sensitivity
(0...60, 60 is highest sensitivity)
(0...60)
316 7 W Downstream pressure limit "PrL" default
value
(1...10)
317 250 W Air bubble size [microliters] (50...1000)
318 20 W Drop-rate window center in [drops/ml] (10...65)
319 1000 W Correction factor ((actual/nominal)*1000)
refer to chapter 5.5
(850...1150)
350 20 W Air summation volume, n * 50 [microliters] (2...40)
351 4 W Air summation time, n * 8 [min] (8..64)
361 500 W Key [ON/OFF] delay
(additional key [STOP] if #4=1)
(0...3000)
362 8 W Display brightness (2...15)
363 10 W Buzzer alarm volume (5...10)
368 300 W Battery discharge time incl. 15min pre-
alarm in [min]
(45...300)
369 5 W Automatic Menu fall back delay time in [s] (5...30)
IV-Set 1 definitions IV-Set 1 parameters
