ARIESAUTOMOTIVE.COM • NEED ASSISTANCE? • 877.287.8634 • B35-2004-RC • PAGE 2
Step 1
Starting underneath the vehicle,
remove the factory tow hooks.
Set the hardware aside for later use.
Step 2
Select the driver-side bracket. Check
the fit between the tow hook and the
bracket.
Lift the tow hook and bracket to the
underside of the frame channel and
reinstall using the factory hardware.
Step 3
Snug the hardware, but do not fully
tighten. Some factory tow hooks may
not clear the bracket and cannot be
reinstalled.
Repeat this step on the passenger side.
Step 4
With help, lift the bull bar into place and
align the mounting tabs of the bull bar on
the outside of the installed brackets.
To Next Page
