15. Fitting the casing
M
N
R
A
Fig. 43
Fitting the casing
Remove the protective film on the casing:
- Locate the lower clips into the slots in the chassis
- Engage hooks N on the casing in notches R on the side panels M operation (Fig. 42)
- Fit the top of the panel in place
- Close the panel mounting clamps (Fig. 43)
- Screw in the two clamp locking bolts A
Note: it is essential to refit both locking bolts A
Fig. 42
