USER INSTRUCTIONS
1. Control panel
31
27
28
26
35
29
Fig. 1
34
32
33
30
Control panel (Fig. 1)
16.- Pressure gauge
26.- Display
27.- On/off push button and power on indicator light
28.- Programming button - domestic hot water temperature
holding function -yellow indicator light
29.- Reset push button and red indicator lock-out light
30.- DHW control knob and temperature setting
31.- Central Heating control knob and temperature setting
32.- Menu button
33.- Reducing button
34.- Increasing button
35.- Setting button
Connecting bracket
Taps shown in Open position (Fig. 2)
39 : Gas service tap
40 : Water service tap
41 : Central heating flow isolating valve
42 : Central heating return isolating valve
43 & 44: Filling taps
45 : Filling loop
Fig. 2
41
42
43
44
45
39
40
16
