Ariston NEXT SFT 14 - Removing the Air Pressure Switch; Removing the Fan

25
6. maintenance
6.1.3 Removing the air pressure switch 6.1.4 Removing the fan
1. Remove the 2 screws from the chassis
A
2. Remove the silicon pipe from the APS
B
2.
Disconnect the electrical connection from the
main pcb
C
3. Release the 3 screws and disconnect the APS
from the bracket
D
1. Release the 2 the two fan fi xing screws, and remove
the silicon pipe
A
2. Disconnect the electrical connection from the
main pcb
B
2. Remove the fan
C
