Ariston NEXT SFT 14 User Manual

26
6. maintenance
6.1.5 Removing the gas collector assembly
6.1.6 Removing the ignitor
1. Disconnect the electrical connections
A
2. Release the support bracket screw
B
1. Remove the earth connection
A
1. Release the 7 screws on the gas collector
B
3. Release the screw also dismounts the igniter
bracket
C
4. Remove the gas collector
D
