Ariston NEXT SFT 14 - Removing the gas valve; Removing the burner;heat exchanger

32
6. maintenance
6.1.16 Removing the gas valve
6.1.17 Removing the burner/heat exchanger
1. Remove the gas collector as detailed in 6.1.5
2. Release the screw, release the silicone pipe from
the fan assembly and remove the gas valve
A
B
3. Disconnect all electrical connections
C
1. Remove electrical connections
A
2. Remove the gas collector and the ignitor
B
