Ariston NEXT SFT 14 - Removing the Detection Electrode; Removing the Ignition Electrode

27
6. maintenance
3. Release the fi xing screw
Remove the spark generator
C
6.1.7 Removing the ignition electrode
6.1.8 Removing the detection electrode
1. Release the 2 screws
A
2. Remove the ignition electrode and disconnect the
male/female connector
B
1. Release the 2 screws
A
2. Remove the electrode and disconnect the electrical
connection
B
