Page 6 User Manual for CD3403
THE DISPLAY
The display is the link between you and the security system. The text messages displayed show where and
when faults or alarms have occurred. The display can also show a list of operations from which you can
select.
Examples of the messages which can appear include:
TUE 23 APR 07.40
The date and time are always displayed, regardless if the system is
armed or not. You can ask the installer to replace it with another
message, if you want.
Arm Menu
If you press Accept (), you enter an option list. This option list can
be used to determine the method used arm the system.
System Arming
The system is being armed. Leave the secured area now.
System Armed
The system is armed.
Not all the messages may appear on your display: it depends how the system has been programmed. It can
show you only the messages you want to see, or those you are authorised to see.
THE LEDS
There are three coloured LEDs (light emiting diodes) on the keypad that let you quickly see if there is a
problem.
Green LED
Power The mains power is on. If it has not been illuminated for a hour and
a power cut is not apparent, contact your installer.
Yellow LED
Trouble If the yellow LED is on, there is a problem in the panel. The type of
problem is shown in the display. Contact your installer. Problems
that may occur include:
♦ Battery fault
♦ Fuse fault
♦ Line fault (if a dialler is connected)
♦ RKP fault (problem with keypads)
♦ EEPROM fault (problem in the system)
When such a problem occurs the keypad buzzer or bells
are activated, if programmed to do so by your installer. The
buzzer/bells are reset (turned off) when you enter your
code.
Red LED
Alarm The alarm is activated. The bells, keypad buzzers and flashing light
may also be active. If a dialler is connected, the alarm is reported
to the central station. When you enter your code, the system
disarms, the bells and the flashing light are switched off, and the
central station receives the report that the alarm has been
deactivated.
The red LED will also illuminate if you disturb an alarm zone during
the exit period, and the internal sounder will be activated.
