33
Technical Specifications
Carendo, Lift and Shower Chair Model BIB2000-01
Safe Working Load (SWL) (Maximum total load) 136 kg (300 lbs)
Maximum weight of lift 64 kg (141 lbs)
Maximum total weight (lift + patient) 200 kg (441 lbs)
Chassis, maximum width 640 mm (25 1/4”)
Width between legs 508 mm (20”)
Clearance under chassis 35 mm (1 3/8”)
Chassis, maximum length 865 mm (34”)
Turning diameter Ø960 mm (37 3/4”)
Lifting stroke range (seat) 530 mm (20 7/8”)
Supply voltage 24V DC
Maximum power 150 VA
Battery NiMH; Arjo NEA 0100
Battery charger NEA 8000
Colors blue/grey
Operating forces of control 2.23 N
Operating forces of brakes 115 N
Degree of protection IPX4
IP: Ingress Protection
X: The protection against contact and ingress
of objects is not specified for this product.
4: Water splashing against the product from
any direction does not effect safety or
essential performance
Degree of protection - Hand control IP X7
IP: Ingress Protection
X: The protection against contact and ingress
of objects is not specified for this product.
7: Immersion up to 1 m of the product does
not effect safety or essential performance
Medical equipment type B
Sound level <58 dB
Mode of operation ED maximum 10%;
Maximum 2 minutes ON;
Minimum 18 minutes OFF
Pollution Degree 2
