Guidance and manufacturer’s declaration – electromagnetic immunity
Immunity test IEC 60601-1-2 test level Compliance level
Electromagnetic
environment – guidance
Electrostatic
discharge (ESD)
EN 61000-4-2
±2kV, ±4kV, ±8kV, ±15kV air
±8kV contact
±2kV, ±4kV, ±8kV, ±15kV air
±8kV contact
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material the relative
humidity level should be at
least 30%
Conducted
disturbances
inducted by RF
fields
EN 61000-4-6
3V in 0,15 MHz to 80 MHz
6V in ISM and amateur radio
bands between 0,15 MHz and
80 MHz
80% AM at 1 kHz
3V in 0,15 MHz to 80 MHz
6V in ISM and amateur radio
bands between 0,15 MHz and
80 MHz
80% AM at 1 kHz
Portable and mobile RF
communications equipment
should be used no closer to
any part of the product,
including cables, than 1.0m,
if the transmitter’s output
power rating exceeds 1W
a
Field strengths from fixed RF
transmitters, as determined
by an electromagnetic site
survey, should be less than
the compliance level in each
frequency range
b
Interference may occur in the
vicinity of equipment marked
with this symbol:
Radiated RF
electromagnetic
field
EN 61000-4-3
Home Healthcare environment
10 V/m
80 MHz to 2,7 GHz
80% AM at 1 kHz
Home Healthcare environment
10 V/m
80 MHz to 2,7 GHz
80% AM at 1 kHz
Proximity fields
from RF
wireless
communications
equipment
EN 61000-4-3
385 MHz - 27 V/m
450 MHz - 28 V/m
710, 745, 780 MHz - 9V/m
810, 870, 930 MHz - 28 V/m
1720, 1845, 1970, 2450 MHz –
28 V/m
5240,5500, 5785 MHz - 9V/m
385 MHz - 27 V/m
450 MHz - 28 V/m
710, 745, 780 MHz - 9V/m
810, 870, 930 MHz - 28 V/m
1720, 1845, 1970, 2450 MHz -
28 V/m
5240,5500, 5785 MHz - 9V/m
Electrical fast
transient/burst
EN 61000-4-4
±1kV SIP/SOP ports
100 kHz repetition frequency
±1kV SIP/SOP ports
100kHz repetition frequency
Power frequency
Magnetic field
EN 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with
accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey
should be considered. If the measured field strength in the location in which the product is used exceeds the
applicable RF compliance level above, the product should be observed to verify normal operation. If abnormal
performance is observed, additional measures may be necessary.
b
Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 1 V/m.
