Arjo Malibu - Safety Belt Storage; Removing the Safety Belt

17
2 Loosen the safety belt by pulling the inner strap (A) at the
side and at the same time lifting the larger buckle clip (B).
See Fig. 6
3 Tighten the safety belt by pulling the outer strap (A) at the
side and at the same time holding the larger buckle clip (B).
See Fig. 7
4 Make sure the safety belt is firmly attached to the patient’s
body.
5 Lock the buckle clips by inserting the smaller buckle clip (A)
into the larger buckle clip (B). See Fig. 8
When not in use
• Make sure that the safety belt is buckled over the seat when
the transfer chair is not in use. See Fig. 9.
Remove
• Remove the safety belt by pulling it away from the knobs at
the back of the chair. See Fig. 10.
Fig. 6
B
A
Fig. 7
B
A
Fig. 8
B
A
Fig. 9
Fig. 10
