Thermometer
Range 10-50 °C
Accuracy +/-1 °C
Resolution 0.1 °C
Operating Conditions
Ambient temperature 5°C – 35°C
Relative humidity 30% - 90% Rh
Atmospheric pressure 800 hPa to 1060 hPa
Transport and Storage
Ambient temperature -20 °C to 70 °C
Relative humidity 10% - 80% at 20 °C
Atmospheric pressure 500 hPa to 1100 hPa
Mains Disconnection Device
Permanently installed in wall. visible and accessible at all times
Mains transient voltage 4 kV*
Creepage distance 3 mm*
Air clearance 1.8 mm*
Direction of movement
Up and down, right and left, clockwise and
counterclockwise
* If local regulations are higher, they must be met.
Water Connections
Cold/hot water connection G 3/4” male (customers connection)
Maximum static pressure 6 bar (600 kPa, 87 psi)
Minimum operating pressure 1 bar (100 kPa, 15 psi)
Minimum drainage capacity 100 l/minute
Temperature - Cold water supply 5 - 20 °C
Temperature - Hot water supply
For WRAS approval the inlet water must be within:
For TMV3 approval the inlet water must be within:
55 - 60 °C
55 - 65 °C
The system is tested up to 80 °C
