Arjo MAXI MOVE - Safety Instructions

KEY: X = Action required on the part of the customer S = Action required on the part of a qualified service technician
7
Test the “Immediate Stop” facility.
See Note 2.
S
Mechanically test the “System Failure Wind Down” facility.
See Note 3.
S
Where a scale is installed, check the accuracy of the unit and recalibrate if
required.
See Note 4.
S
Examine the two lifting straps over the entire length. Replace the straps if
there is evidence of wear or damage.
S
Perform a torque tightening check. Identify type of legs (see Fig. 8) and
perform torque tightening check according to leg model and material.
See Note 5.
S
Check the 2.5 kg (4 lbf) force required to rotate the jib pivot. Adjust screw
if required. See Fig. 9 for location.
S
Check the gap between the “T” piece flange and jib. If more than 2 mm,
replace jib bushings (minimum gap is 1 mm).
See Fig. 9 for location of gap.
S
Verify the width of the legs (see Fig. 10). First, remove the leg covers.
With the legs closed, measure center to center at the ends near the front
castors. Adjust only if dimension “A” is shorter than 650 mm (25 1/2”) for
Standard height leg model (KMCS
**) and Low height model (KMCL**)
or shorter than 695 mm (27 3/8”) for Extra Low height leg model
(KMCE
**).
S
It is recommended to replace the two lift straps every 2 years if they are
used. If the straps appear damaged or worn before then, replace the straps
immediately.
Lubricate the two top strap rollers.
S
Action
Maxi Move Accessories
Slings Battery Charger
Before
Every Use
Every
Week
Every 12
Months
Every 2
Years
Before
Every Use
Every
Week
Every 12
Months
Every 2
Years
Before
Every Use
Every
Week
Every 12
Months
Every 2
Years
Preventive Maintenance Schedule
001.25065.EN rev. 9
