installation &
operating instructions
Series 4300, 4360 and 4380
Vertical in–line pumps
11
fig. 2.11 Motor lifting hook supported.
Seismically Rated Snubbers or
Pads and Concrete Foundation
fig. 2.12 Mounted on rigid base without flexible
connectors;
Seismically Rated Snubbers or
Pads and Concrete Foundation
fig. 2.13 Tapped collection well on series 4300
Seismically Rated Snubbers or
Pads and Concrete Foundation
Series 4300 seal leaks or
condensate drain hole.
Plumb to drain for area
cleanliness.
