Armstrong The Brain DRV25 User Manual

13
Armstrong International
221 Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
armstronginternational.com/brain
C
H
CH
From Hot
Water Supply
Return to
Hot Water
Supply Inlet
Cold Water
Supply
DRV
DRV
Mixed Flow
Mixed Flow
Outlet
Outlet
®
THE BRAIN
DRV25
®
THE BRAIN
DRV25
Sink
Shower
Thermometer
Strainer
Cold Water
Hot Water
Mixed Water
Check Valve
Recirculation Pump
Items are installer
supplied
System Layout
- Legend -
Isolation Valve
DRV25 Assembly
Swing Check Valve*
- Legend -
Thermometer
Isolation Valve
*Orientated for piping
schematic detail only.
Must be installed in
horizontal plane.
Figure 13-1. DRV25 Dual Valve Installation
Note: DRV25 inlet connections are 1″.
Bon à savoir: La tubulure d’entrée du DRV25 est 1”.
