PCB Connections
Thermistors (CN5)
Battery
Backup
(CN4)
Modbus End of
Line Termination
(CN10)
Touch Sensor
Connector
(CN12)
Modbus
Connector
(CN7)
Motor Opto Loom
(CN6)
Mains Power
(CN8)
