Aros SENTRY MPS-HP User Manual

0MNA080A55-GB REV 01 page 71 / 75
7. General characteristics
Mechanical Data
SENTRY MPS-HP Power (kVA)
100 120 160 200 250
Width MPS (mm) 800 1000
Depth / height (mm) 850 / 1900
Ventilation Forced by internal fans
Degree of protection of the cabinet IP20 (greater degree of protection than required)
Cable entry Underneath/Back
Colour RAL 7035 (light grey)
Max current dispersion 300mA max
Noise at 1m from front (from 0 to full
load) -(dBA)
65 65 68 68 68
Electrical Data
SENTRY MPS-HP Power (kVA)
100 120 160 200 250
INPUT
Rated voltage 400Vac 3-phase
Rated voltage tolerance without
contrib. of battery
-10%, +20%
Voltage tolerance in battery mode
- 20% , + 20%
Input frequency tolerance from 45 to 65Hz
Rated current absorbed (400 V) (A)
126 151 200 250 312
Rated power absorbed (400 V)-(kVA)
87 104 138 173 216
Maximum current absorbed at full
load and with battery recharging (A)
145 173 229 288 359
Maximum power absorbed at full load
and with battery recharging (kVA)
100 120 159 199 248
Power factor at rated voltage (400 V)
and battery charge from 25% to 100%
of the load
>0.99
Current Harmonic Distortion (THDi)
% load
rated load at 100%
75%
25÷50%
≤ 3
≤ 5
≤ 8
Rectifier progressive feeder (Power
Walk-in)
from 0 to 30 seconds (configurable)
Delay on rectifier progressive feeder
(Power Walk-in delay timer))
from 0 to 120 seconds (configurable)
Electrical Data
SENTRY MPS-HP Power (kVA)
100 120 160 200 250
INTERMEDIATE D.C. CIRCUIT
Monoblocks/ Number of Pb elements 40 / 240
Ripple voltage with battery charging
(%)
Approx. 0
Recharge current (A)
Full load 20 24 32 40 50
Load 90% 36 44 58 70 90
Load 80% 52 64 84 100 130
Load ≤ 70% 67 83 106 130 165
