Array electronic 372 Series User Manual

40
selection and parameter setting menu.
5
Press
key to turn on the load.
0.000V 0.000A
1.5000
Ω CRL ON
6
Check the present power value with
, .
0.000V 0.000A
1.5000
Ω 0.000W
For the above operating procedures, the corresponding SCPI commands should be:
MODE CRL ；Sets the mode
RES 1.5 ；Sets the resistance value
INP ON ；Turns on the load
Example 2: Set the resistance value to 1.8Ωin CRL.
Turn on the load, and there are two ways to set the resistance value.
Solution 1:
Procedures Operation Descriptions Display
1
Press
key to enter into the mode selection and
parameter setting menu.
MODE： CRL
RES ： 1.5000
Ω
2
Use Entry keys or use the knob together with
,
keys to input the resistance value to 1.8.
MODE： CRL
RES ： 1.8000Ω
3
Press key to confirm and exit the mode
selection and parameter setting menu.
0.000V 0.000A
1.8000
Ω CRL OFF
4
Press
key to turn on the load.
0.000V 0.000A
1.8000
Ω CRL ON
Solution 2:
Procedures Operation Descriptions Display
1
Move the cursor to the tenths with
key.
0.000V 0.000A
1.5
000Ω CRL OFF
2 Rotate the knob to set the tenths to 8.
(Rotating the knob will change the set value
immediately. The set value will become effective at
input at once when the load is turned on.)
0.000V 0.000A
1.8
000Ω CRL OFF
3
Press
key to turn on the load.
0.000V 0.000A
1.8
000Ω CRL ON
For the above operating procedures, the corresponding SCPI commands should be:
MODE CRL ；Sets the mode
RES 1.8 ；Sets the resistance value
INP ON ；Turns on the load
Note: CRH /CRM/CRL will be shown respectively in the lower right corner of the display when
