Array electronic 372 Series User Manual

62
7
Press
key to turn off the load.
0.000V 0.000A
2.000
A CCH OFF
For the above operating procedures, the corresponding SCPI commands should be:
MODE CCH ；Sets the mode
CURR 2 ；Sets the current value to 2A
CURR:RISE:RATE 0.002 ；Sets the current rise rate in CC mode to 0.002A/us
CURR:FALL:RATE 0.005 ；Sets the current fall rate in CC mode to 0.005A/us
INP ON ；Turns on the load
INP OFF ；Turns off the load
4.14.6 Trigger Function Selection
Example: Select “Tran” in trigger function selection (Trig Function).
Procedures Operation Descriptions Display
1
Press
key to enter into the main menu.
Load Default：
Yes *No
2
Use
key to select the menu item “Trig Function”; use the
knob or
key to select the parameter “Tran”. Press key
to confirm.
Trig Function：
*Tran List
3
Press
key to exit the main menu.
0.000V 0.000A
0.000
A CCH OFF
For the above operating procedures, the corresponding SCPI commands should be:
TRIG:FUNC TRAN ；Selects transient operation (TRAN) for trigger function
4.14.7 Knob Function
Example: Enable the knob function.
Procedures Operation Descriptions Display
1
Press
key to enter into the main menu.
Load Default：
Yes *No
2
Use
key to select the menu item “Knob”; use the knob or
key to select the parameter “On”. Press key to confirm.
Knob：
*On Off
3
Press
key to exit the main menu.
0.000V 0.000A
0.000
A CCH OFF
4.14.8 Key Sound
Example: Enable the key sound.
Procedures Operation Descriptions Display
1
Press
key to enter into the main menu.
Load Default：
Yes *No
2
Use
key to select the menu item “Key Sound”; use the knob
Key Sound：
*On Off
