57
power-on settings.
Procedures Operation Descriptions Display
1 Set the mode to CCL; set the current value to 2A; turn on the load
please refer to 4.5.1 for detailed operations).
0.000V 0.000A
2.0000A CCL ON
2
Press
key + key to enter into the saving menu.
Save File
No. 1
3 Press Entry keys or the knob to select the Location 0 for saving.
Save File
No. 0
4
Press key to confirm and exit the load saving menu.
0.000V 0.000A
2.0000A CCL ON
For the above operating procedures, the corresponding SCPI commands should be:
MODE CCH ；Sets the load to CCH status
CURR 2 ；Sets the current value to 2A
INP ON ；Turns on the loas
*SAV 0 ；Saves the present settings in Location 0 in EEPROM
Example 2: Based on the above example, set the mode to CV; set the voltage value to 40V; turn
off the load; recall the values saved in Location 0 in EEPROM. The detailed operations are shown
below:
Procedures Operation Descriptions Display
1 Set the mode to CV; set the voltage value to 40V; turn off the loa
(please refer to 4.5.2 section for detailed operations).
0.000V 0.000A
40.000V CV OFF
2
Press
key + key to enter into the recalling menu.
Recall File:
No. 0
3 Press Entry keys or the knob to select the recalled Location 0. Recall File:
No. 0
4
Press
key to confirm and return.
0.000V 0.000A
2.0000A CCL ON
For the above operating procedures, the corresponding SCPI commands should be:
MODE CV ；Sets the CV mode
VOLT 40 ；Sets the voltage value to 40V
INP OFF ；Turns off the load
*RCL 0 ；Recalls the values saved in location 0 in EEPROM
4.11 Clearing Protection Settings
The operating procedures for clear protection settings are shown below:
1. Eliminate the reason that causes the protection status.
2. Press
key + key.
Example 1: Clear RV protection of the load. The detailed operations are shown below:
Procedures Operation Descriptions Display
1 Connect the power supply to the load again. 0.000V 0.0000A
2.0000
A RV OFF
