Array electronic 372 Series User Manual

43
(short circuit) item with key.
2
Use key or knob to set On, and press key to
confirm.
Short：
*On Off
3
Press
key to exit the main menu. The display shows “s”
to indicate in CV mode.
0.000V 0.000A
0.000V sCV OFF
4
Press
key to enter into the mode selection and parameter
setting menu; use
key to select CCH; press key to
confirm and exit the mode selection and parameter setting
menu.
0.000V 0.000A
44.000A sCCH OFF
5
Press
key to turn on the load.
0.000V 0.000A
44.000A sCCH ON
For the above operating procedures, the corresponding SCPI commands should be:
INP:SHOR ON ; Sets the load to short circuit operation
MODE CCH ; Sets the mode
INP ON ; Turns on the load
Example 2: Based on the last example, exit the short circuit operation, and turn off the load.
Procedures Operation Descriptions Display
1
Press
key to enter into main menu, and select Short
(short circuit) item with
key.
Short：
*On Off
2
Use
key or knob to set Off, and press key to
confirm.
Short：
On *Off
3
Press
key to exit the main menu. On the display, “s”
disappears in CCH status.
0.000V 0.000A
0.000
A CCH ON
4
Press
key to turn off the load.
0.000V 0.000A
0.000
A CCH OFF
For the above operating procedures, the corresponding SCPI commands should be:
INP:SHOR OFF ；Sets the load to exit the short circuit operation
INP OFF ；Turns on the load
4.7 Transient Operation
The operating procedures for transient operation are shown below:
