Figure 22: ALEXA with EVF-1, VEB-3 and cable KC-151S
8.4 Center Camera Handle CCH-1
The Center Camera Handle CCH-1 is attached to the camera top with
three captive 3mm hex socket head screws (two at the front and one at
the back). Ensure that the CCH-1 is securely fastened before attempting
to lift the camera from it.
Figure 23: Camera with CCH-1, side view
