Arris Touchstone TM3202G - Patterns: Startup Sequence

Chapter 7: Using the Telephony Modem
Release 32 STANDARD 1.2 August 2016 Touchstone TM3202G Telephony Modem User Guide
© 2015-2016 ARRIS Enterprises LLC. All Rights Reserved. 34
Mode Power Ethernet
(LEDs on rear
panel connector)
US/DS Online Tel 1 / Tel 2 Battery
No AC
Power
No Battery
Off Off Off Off Off Off
Firmware
Upgrade
On (normal
operation)
Flash On (normal
operation)
(normal
operation)
Patterns: Startup Sequence
The following tables show the Telephony Modem light patterns during each phase of the
startup sequence. There are two phases of startup; the telephony phase and the cable
modem phase. Both are outlined below.
Telephony Startup Sequence
Power, US/DS,
Online
Telephone 1 Telephone 2 Battery Description
Off Off Off Off No power to modem
Flash Flash Flash Flash Power-on Self Test
See Cable Modem Startup Sequence (page 34)
On Flash Off Off Retrieving telephone
network information
On Off Flash Off Retrieving telephone
line information
On Flash Flash Off Activating telephone
service
Normal Operation
