Making USB Connections
5 Connect one end of the USB cable to the USB port on the computer, and the
other end to the USB port on the back of the Telephony Modem (C).
Your computer should detect the Telephony Modem and begin installing the
drivers. See Installing USB Drivers on Your PC for driver installation details.
Making Telephone Connections
6 Connect one end of the telephone cable to the telephone port on the back
of the Telephony Modem (A or B). Connect the other end to the telephone.
Note: If you have a TM502G Telephony Modem and a phone with two sep-
arate lines on a single RJ-11 cord, it must be plugged into the port labeled
“Tel 1/2”.
