Touchstone TM502 Telephony Modem User’s Guide 47
Getting Battery USB Ethernet
Safety Started Installation Installation Drivers Configuration Usage Troubleshooting Glossary
Indicator Lights for the TM502G Model
The Touchstone Telephony Modem has eight indicator lights to assist in troubleshooting. Note that
not all models have a Battery light.
Indicator Lights: Normal Operation
The following table shows light patterns during normal operation.
Mode Power DS US Online Link Tel. 1/Tel. 2 Battery
AC
Power
Good
On
On =
Connected
to the
Internet
Flash =
Not
connected
to the
Internet
On =
Connected
to the
Internet
Flash =
Not
connected
to the
Internet
On =
Internet
Available
Off =
Internet
not
available
On =
Computer
Connected
Off =
Computer not
connected
Flash =
Computer
Activity
On =
On-hook
Flash =
Off-hook
Off = disabled
On =
Battery
good or
low
Off =
Battery
missing
Flash =
Battery
bad
No AC
Power
Good
Battery
Flash Off Off Off Off
On =
On-hook
Flash =
Off-hook
Off = disabled
Off =
Battery
power
Flash =
Battery
bad
No AC
Power
No
Battery
Off Off Off Off Off Off Off
Software
Upgrade
On Flash Flash On
(normal
operation)
(normal
operation)
(normal
operation)
