Arthrex AR-400UBC User Manual

Universal DrillSaw Battery Charger User’s Guide
DFU-0256-1 Rev. 0 Page 9 of 35
2
2
.
.
4
4
.
.
2
2 AR-400UBC Universal DrillSaw Battery Charger – Rear View
Figure 2 shows the rear panel of the AR-400UBC. The features are identified in Table
2 below.
Figure 2 Rear Panel of the Charger
Table 2 Rear Panel of the Charger
6.
ON/ OFF Power Switch
7.
Supply main input Plug
8.
Supply main output to connect a second charger to an existing
charger
9.
Hex-wrench
8 7
9
6

Arthrex AR-400UBC Specifications

General

Brand	Arthrex
Model	AR-400UBC
Category	Battery Charger
Language	English
