Universal DrillSaw Battery Charger User’s Guide
DFU-0256-1 Rev. 0 Page 17 of 35
4.2 Basic Setup Procedure for the AR-400UBC Charger
NOTE: Section 5.0, Operation, explains how to use the charger.
NOTE: See Section 4.3 for specific assembly instructions.
1. Place the AR-400UBC on a flat, dry surface.
2. Connect the receiver end of the power cord for the AR-400UBC into the AC
socket and the plug end to the facility AC mains supply.
3. Install the charging bay.
4. Power ON charger.
5. Allow the charger to fully initialize.
All charger bays can be used simultaneously, with any combination of
battery types.
The charging process starts automatically, once the battery types have been
identified. The orange battery symbol display lights up and starts blinking.
This symbol may be green, depending on the level of charge that the battery
has when placed on the charger.
Depending on the charge status and type of battery, it can take as little as 15
minutes to charge a battery.
Once the battery is fully charged, the green battery symbol will be completely
filled. The charger then switches to a maintenance charge . The battery may
be left on the charger until it’s needed. Leave the device powered on, to
ensure that the battery is always fully charged.
If the battery is removed from the charger before the green display lights up
completely, it will not be fully charged.
WARNING!
Use only Arthrex approved accessories. Other accessories may result in increased
emissions or decreased immunity of the system. Contact your Arthrex representative
for a complete list of accessories. DO NOT modify any accessory. Failure to comply
may result in patient and/or operating room staff injury.
WARNING!
Do not use in the presence of flammable anesthetics or oxidizing gases such as
nitrous oxide, oxygen, or endogenous gases. All oxygen connections must be leak
free for the duration of the surgical procedure.
