Universal DrillSaw Battery Charger User’s Guide
DFU-0256-1 Rev. 0 Page 20 of 35
Table 11 Battery Attachment and Removal
These pictures represent how to insert a battery onto a charging
bay. The black arrows indicate the direction of insertion.
Note: AR-300L batteries are placed on the charger in the same
manner as the AR-600L batteries.
These pictures represent a battery that has been fully engaged on
the charging bay.
Note: The Charger should recognize the battery and visually
indicate charging via the display screen within a few seconds.
