4 Aruba 630 Series Campus Access Points | Installation Guide
USB 2.0 Interface
The USB 2.0 interface located on the top of the 630 Series is compatible with selected cellular modems and
other peripherals. When active, this interface can supply up to 5W/1A to a connected device.
Reset Button
The reset button can be used to reset the access point to factory default settings or turn off/on the LED display.
Use one of the following methods to reset the access point to factory default settings:
To reset during normal operation:
1.Hold the reset button for more than 10 seconds while the access point is running.
2.Release the reset button.
To reset during power up, hold the reset button while the access point is powering up.
The system status LED will flash again within 15 seconds indicating that the reset is completed. The access
point will now continue to boot with the factory default settings.
To toggle the LED display between Off and Blinking:
During the normal operation of the access point, shortly press and release the reset button for less than 10
seconds using a small, narrow object, such as a paperclip.
Power
Both E0 and E1 ports support PoE-in (AP is a PoE-PD device), allowing the device to draw power from compliant
PoE power sources. If PoE is not available, a proprietary AP-AC2-12B power adapter (sold separately) can be
used to power the access point. When both PoE and DC power sources are available, the DC power source takes
precedence. In that case, the access point simultaneously draws a minimal current from the PoE source. In the
event that the DC source fails, the access point switches to the PoE sources.
The Intelligent Power Monitoring (IPM) feature may also be used to manage the power consumption
preferences for this device. When enabled, the user may enable/disable power restrictions for the access point
using Aruba’s AP management software.
Table 3 lists operational restrictions when the access point is powered by different power options.
Table 3 Power Options and Operational Restrictions
Before You Begin
Refer to the sections below before beginning the installation process.
Power Source IPM Restrictions
DC power n/a No restrictions, all capabilities available
PoE 802.3bt n/a No restrictions, all capabilities available
PoE 802.3at disabled USB disabled (can be overruled in software)
PoE 802.3af disabled USB disabled (can be overruled in software), AP in dual
radio mode, E1 or E0 disabled (one without PoE or E1),
remaining wired port limited to 1Gbps.
PoE 802.3at enabled All capabilities available (features may be disabled per IPM
configuration)
PoE 802.3af enabled All capabilities available (features may be disabled per IPM
configuration)
FCC Statement: Improper termination of access points installed in the United States configured to non-US
model controllers will be in violation of the FCC grant of equipment authorization. Any such willful or intentional
violation may result in a requirement by the FCC for immediate termination of operation and may be subject to
forfeiture (47 CFR 1.80).
