6 Aruba 630 Series Campus Access Points | Installation Guide
accessories and must be ordered separately. Refer to the online ordering guide at
https://www.arubanetworks.com
Software
For instructions on choosing operating modes and initial software configuration, refer to the AP Software Quick
Start Guide.
Verifying Post-Installation Connectivity
The integrated LED on the access point can be used to verify that the access point access point is receiving power
and initializing successfully (see Table 1-Table 2). Refer to the AP Software Quick Start Guide for further details
on verifying post-installation network connectivity.
Electrical and Environmental Specifications
For additional specifications on this product, please refer to the product data sheet at www.arubanetworks.com
Electrical
Ethernet:
E0 port: 100/1000/2500Base-T auto-sensing MDI/MDX wired RJ45 network connectivity port
E1 port: 100/1000/2500Base-T auto-sensing MDI/MDX wired RJ45 network connectivity port
Power:
12V DC power interface, support powering through AC-to-DC power adapter (AP-AC2-12B)
Power over Ethernet (PoE): 802.3af, 802.3at or 802.3bt compliant source
Environmental
Operating:
All Aruba access points should be professionally installed by an Aruba-Certified Mobility Professional (ACMP).
The installer is responsible for ensuring that grounding is available and meets applicable national and electrical
codes. Failure to properly install this product may result in physical injury and/or damage to property.
Tous les points d'accès Aruba doivent impérativement être installés par un professionnel agréé. Ce dernier doit
s'assurer que l'appareil est mis à la terre et que le circuit de mise à la terre est conforme aux codes électriques
nationaux en vigueur. Le fait de ne pas installer correctement ce produit peut entraîner des blessures
corporelles et / ou des dommages matériels.
The installer is responsible for securing the access point onto the ceiling tile rail. Failure to properly install this
product may result in physical injury and/or damage to property.
Use of accessories, transducers and cables other than those specified or provided by the manufacturer of this
equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this
equipment and result in improper operation.
Aruba access points are classified as radio transmission devices, and are subject to government regulations of
the host country. The network administrator(s) is/are responsible for ensuring that configuration and operation
of this equipment is in compliance with their country’s regulations. For a complete list of approved channels in
your country, refer to the Aruba Downloadable Regulatory Table at https://asp.arubanetworks.com.
If a power adapter other than the Aruba-approved adapter is used in the US or Canada, it should be NRTL listed,
with an output rated 12V DC, minimum 0.75A, marked “LPS” and “Class 2,” and suitable for plugging into a
standard power receptacle in the US and Canada.
