2 Aruba 630 Series Campus Access Points | Installation Guide
Table 1 System Status LED
2GHz/5GHz/6GHz Radio Status LEDs
The 2GHz/5GHz/6GHz Radio Status LEDs indicate the operating mode of the access point’s 2GHz/5GHz/6GHz
radios. See Table 2.
Table 2 2GHz/5GHz/6GHz Radio Status LEDs
LED Display Settings
The LEDs have three operating modes that can be selected in the system management software:
Default mode: refer to Table 1and Table 2
Off mode: all LEDs are off
Blink mode: all LEDs blink green (synchronized)
To force the LEDs into off mode or back to software defined mode, press the reset button for a short duration
(less than 10 seconds).
Color/State Meaning
Off Device Powered off
Green- solid Device ready, fully functional, no network restrictions
Green- blinking
1
1. Blinking: one second on, one second off, 2 seconds cycle.
Device booting, not ready
Green- flashing off
2
2. Flashing off: mostly on, fraction of a second off, 2 seconds cycle.
Device ready, fully functional, either uplink negotiated in sub-optimal speed
(<1Gbps)
Green- flashing on
3
3. Flashing on: mostly off, fraction of a second on, 2 seconds cycle.
Device in deep-sleep mode
Amber- solid Device ready, restricted power mode (limited PoE power available, or IPM
restrictions applied), no network restrictions
Amber- flashing off Device ready, restricted power mode (limited PoE power available, or IPM
restrictions applied), uplink negotiated in sub-optimal speed
Red System error condition - Immediate attention required
Color/State Meaning
Off Device powered off, or radio disabled
Green- solid Radio enabled in access mode
Green- flashing off Radio enabled in uplink or mesh mode
Amber- solid Radio enabled in monitor or spectrum analysis mode
Pressing the reset button for longer than 10 seconds may cause the AP to reset and return to factory default
state.
