ClearPass C1000 Appliance Specifications
AC input frequency 50/60 Hz auto-selecting
Environmental
Operating temperature 5º C to 35º C (41º F to 95º F)
Operating vibration 0.26 G at 5 Hz to 200 Hz for 15 minutes
Operating shock 1 shock pulse of 20 G for up to 2.5 ms
Operating altitude -16 m to 3,048 m (-50 ft to 10,000 ft)
ClearPass C2000 Hardware Appliance
The ClearPass Policy Manager C2000 hardware appliance (SKU: JZ509A) is a RADIUS/ TACACS+ server that
provides advanced policy control for up to 5,000 simultaneous sessions.
The ClearPass C2000 appliance ships with two x 1TB SATA disk drives. These drives are managed by an LSI
RAID-1 controller. The drives are configured as a RAID-1 pair. The LSI controller presents to ClearPass a single
virtual 1TB drive, masking the two underlying physical drives.
Figure 2 shows the ports and components on the rear panel of the ClearPass C2000 hardware appliance. The
function of each of these ports and components is described in Table 1.
The image of the ClearPass C2000 hardware appliance shown here includes the optional redundant power supply.
Figure 2 Ports and Components on the ClearPass C2000 Hardware Appliance
Callout
Number
C2000 Port/Component
1 and 2 USB ports (2)
3 iLO (Integrated Lights-Out) port and Management port (eth0)
4 VGA Connector
5 Data port (eth1)
9 ClearPass 6.7 Getting Started Guide
