ClearPass C2000 Appliance Specifications
Dimensions (WxHxD 17.11” x 1.70” x 150.5”
Weight (max configuration) Up to 19.18 lbs
Power Specifications
Power consumption (maximum) 250 watts
Power supply HPE 900W AC 240 VDC Power Input FIO Module
NOTE: The optional HPE 900W Redundant Power Supply
supports 100 VAC to 240 VAC; this power supply also
supports 240 VDC.
Power redundancy Optional
AC input voltage 100/240 VAC auto-selecting
AC input frequency 50/60 Hz auto-selecting
Environmental Specifications
Operating temperature 10º C to 35º C (50º F to 95º F)
Operating vibration Random vibration at 0.000075 G²/Hz, 10Hz to 300Hz, (0.15
G’s nominal)
Operating shock 2 G's
Operating altitude 3,050 m (10,000 ft)
ClearPass C3000 Hardware Appliance
The ClearPass Policy Manager C3000 hardware appliance (SKU: JZ510A) is a RADIUS/ TACACS+ server that
provides advanced policy control for up to 25,000 simultaneous sessions.
The ClearPass C3000 appliance ships with six Serial-Attach SCSI (SAS) (10K RPM) 600GB Hot-Plug hard drives
(RAID-10 controller).
The LSI controller presents to ClearPass a single virtual 1.675 TB drive, masking the underlying two physical
drive groups (two groups of two mirrored drives).
Figure 3 shows the ports and components on the rear panel of the ClearPass C3000 hardware appliance. The
function of each of these ports and components is described in Table 1.
The image of the ClearPass C3000 hardware appliance shown here includes the optional redundant power supply.
11 ClearPass 6.7 Getting Started Guide
