10
Device description
1
2
3
4
5
6
7
8
9
11
12
13
14
10
15
1 Impact protection
2 Choke
3 Rear cutting height adjustment
4 Starter grip
5 Tank filler spout
6 Tank ventilation
7 Handlebar with control elements
8 Fuel valve
9 Fixing of bar
10 Spark plug connector
11 Ventilation grid
12 Silencer
13 Air filter
14 Front cutting height adjustment
15 Type plate
